verified_user Warranty Info

Warranty Guarantee: 25-year limited warranty on stainless steel filter head, 1-year limited warranty on disposable filter cartridge

Aqua-Pure

AQUA-PURE-AP904

3M Aqua-Pure AP904 Carbon Water Filter

.price-ui--loading { display: block !important; opacity: 1 !important; }

$588.68

Solves difficulties with hard water and scale buildup
Protects household appliances from scale buildup prolonging their life
Lasts for 12 months or 100,000 gallons
Installs onto water line

format_list_bulleted Features & Specs

Package Qty: 1

Manufacturer: 3M

Manufacturer's Id: 5621104

UPC: 016145266997

Media: Carbon Block with Non-Woven Pleat Media and Scale Inhibitor

Primary Filter Media: Activated Carbon Block

Operating Pressure (psi): 25 - 125

Operating Temperature (°F): 40 - 100

Operating Temperature (°C): 4.4 - 37.8

Warranty Guarantee: 25-year limited warranty on stainless steel filter head, 1-year limited warranty on disposable filter cartridge

Brand: Aqua-Pure

Advertised Size: 20 x 2-1/2

Fitting Size (in): 1 in

Micron Rating Nominal: 5

Fitting Type: NPT

Flow Rate (gpm): 20.0

Includes: 304 Stainless Steel head assembly with mounting bracket, AP917HD-S filter cartridge

description Instructions

Shut off main water supply. Drain water from water lines and open faucet downstream of install location.
Remove filter cartridge from filter head and set aside.
Cut pipe to length needed to install filter and recommended bypass.
Assemble filter on bypass system. Use three three shut-off valves and one filtration unit. Use copper pipe and sweated connections to assemble system.
Install system (valves, piping and filter head) into water supply system.
Use supplied bracket or pipe hangers to support the system.
Install filter cartridge into head. Make sure internal key ring is positioned correctly by rotating to the right until it snaps into place.
While water is running thru faucet, close valves 2 and 3 valve, open valve 1. Make sure no leaks allow water to flow through faucet.
While water is running through faucet, close valve 1, open valves 2 and 3. Allow filter to fill up.
Check for leaks. If no leaks occur, open faucet and let run for 15 minutes or until air is flushed from system.

file_download Downloads

User Guide

Installation Guide

workspace_premium Certifications

NSF/ANSI Standard 42

warning_amber Contaminants Reduced

Chlorine

Dirt Sand Sediment

Hard Scale

Particulates

Rust And Corrosion

filter_alt Filter Life

Filter Life (gallons): 100000

Filter Life (months): 12 months

verified_user Warranty Info

Warranty Guarantee: 25-year limited warranty on stainless steel filter head, 1-year limited warranty on disposable filter cartridge

warning

Prop65 warning applies to products that contain carbon media. Click here for more details

WARNING: This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov

help Product Details

The 3M Aqua-Pure AP904 Carbon Water Filter is equipped to combat hard water and scale buildup with the ability to handle up to 100,000 gallons of water. Decreasing hardness and scale in your water increases the life of your appliances. Furthermore, this filter lasts for 12 months and is vigorously made with corrosion resistant and sturdy material, order today!

3M Aqua-Pure AP904 Carbon Water Filter

AQUA-PURE-AP904 is comparable with the following part number(s)

AQUA-PURE-AP904 fits the following model number(s)
