PENTEK-158642
Pentek 158642 3G IB Slim Line #10 Blue 3/8-Inch Housing w/pr
$24.48
format_list_bulleted Features & Specs
Package Qty: 1
Manufacturer: Pentair Water
Manufacturer's Id: 158642
UPC: 799932590191
Actual Size (in): 13 3/8 inches (height) x 5 3/8 inches (width)
Brand: Pentek
Fitting Size (in): 38 in
Height (in): 13.38 in
Width (in): 5.38 in
Materials of Construction: Button Assembly: 300-Series Stainless Steel, EPDM, and Polypropylene, Housing: Polypropylene, Cap: Reinforced Polypropylene, O-Ring: Buna-N
Maximum Temperature (f): 125
Fitting Type: NPT
Flow Rate (gpm): 5.0
The Pentek 158642 3G Slim-Line housing has 3/8-inch NPT inlet/outlets. The Pentek 3G IB 158642 water filter housing has an integrated bracket so a separate bracket does not need to be purchased. The slim design of the housing reduces space required for installation without sacrificing capacity. The Pentek 158642 housing includes a pressure-relief/bleed button. The 158642 water filter housing has leak-proof sealing with a top-seated Buna-N o-ring. The Pentek 158642 housing accepts proprietary Seal-Safe double o-ring sealing cartridges as well as standard Double Open End (DOE) cartridges. The Pentek 3G IB 158642 filter housing can use any 10-inch L x 2.5-inch W water filter. Two number 10 Standard housings can be connected with a pipe nipple or pipe union. There are several pipe nipples available that can be used to connect two number 10 Standard Housings. Use the NP-38 pipe nipple to connect two number 10 Housings with 3/8-inch inlet/outlets.
PENTEK-158642 is comparable with the following part number(s)
- 158642
