    Tier1

    TIER1-ECP5-BB

    10 X 4.5 Pleated Cellulose Replacement Filter by Tier1 (5 micron)

    • Pleated Cellulose filter media

    • Brings you cleaner water along with an easy installation

    • 30 day 100% satisfaction guarantee

    • Fits many common housings with a 10 inch by 5 inch size

    format_list_bulleted Features & Specs
    Package Qty: 1
    Manufacturer: Tier1
    Manufacturer's Id: ECP5-BB
    UPC: 700355940722
    Actual Size (in): 9 3/4 inches (length) x 4 1/2 inches (outside diameter)
    Primary Filter Media: Pleated Cellulose
    Operating Temperature (°F): 40 - 125
    Operating Temperature (°C): 4.4 - 51.7
    Warranty Guarantee: Unconditional Product Guarantee for Life of the Product
    Brand: Tier1
    Advertised Size: 10 x 4-1/2
    Length (in): 9.75 in
    Outside Diameter (in): 4.5 in
    Media Type: Sediment Filter
    UPC's For Search: 700355940722 | 10051678490430 | 051678490433 | 70033663005128 | 033663005129
    Micron Rating Nominal: 5
    description Instructions
    1. Turn off water supply. Press red pressure-relief button (if present)
    2. Unscrew housing. Remove large o-ring, wipe clean and set aside
    3. Discard used filter cartridge. Wash housing with dish soap and warm water using a nonabrasive sponge or cloth. Rinse thoroughly
    4. Fill 1/3 with water. Add about 1 tablespoon of bleach and scrub to disinfect. Rinse thoroughly
    5. Lubricate o-ring with clean silicone grease. Change o-ring if any damage cuts or degradation are present. Insert o-ring in groove
    6. NOTE: This step is important to ensure a proper housing seal. Make certain the o-ring is seated level in the groove
    7. Insert new filter cartridge
    8. Screw housing onto the cap and hand-tighten. Do not over tighten. Make sure cap standpipe slips into cartridge
    9. Turn on water supply. Press pressure-relief button (if present). Check for leaks before leaving installation
    warning_amber Contaminants Reduced
  • Dirt Sand Sediment
  • Oxidized Iron
  • Particles
  • Sand
  • Sediment
  • filter_alt Filter Life
    Filter Life (gallons): 6 months
    verified_user Warranty Info
    Warranty Guarantee: Unconditional Product Guarantee for Life of the Product

    The Pentek ECP5-BB comparable by Tier1 is a 10 x 5 inch whole house sediment water filter for commercial and residential applications that require reduction of sand, sediment, rust, and dirt. Pleated Cellulose filter media headlines this 5 micron sediment filter that will meet your filtering challenges head on. Order today!


    TIER1-ECP5-BB   is comparable with the following part number(s)

    • 1019138
    • 4021341
    • 155184-27
    • 255490-43
    • American Plumber 155184
    • American Plumber W5CPHD
    • Ametek CP5-BB
    • Ametek ECP5-BB
    • Bruner CP5-BB
    • CP5-BB
    • CP5-BBS
    • CP5-BBS-D
    • CP5-BS
    • ECP5-BB
    • FM-BB-10-5
    • GPC5
    • HD-950
    • Keystone GPC5
    • Kleen Plus CP5-BB
    • OmniFilter RS15
    • PC05-BB-S
    • Pentair CP5-BB
    • Pentek 255490-43
    • Pentek CP5-BB
    • PENTEK-ECP5-BB
    • Plymouth CP5-BB
    • PSC-45-1005
    • RS15
    • RS15-2-01
    • RS15-2-02
    • RS15-2-05
    • RS15-R-05
    • SPC-45-1005
    • SPF-45-1005
    • US Filter CP5-BB
    • W5CPHD
    • WB-HB-10-5W
    • RB-CP5-BBS

    TIER1-ECP5-BB   fits the following model number(s)

    • AQUAPURE-AP101T
    • WHIRLPOOL-WHKF-DWHBB
